1-1/4″ Steel Ball Bearing Sliding Door Nylon Roller Assembly, Northrup

This is a F-tab patio door roller assembly with a 1-1/4 in. concave steel ball bearing roller. When the corner screw passes through the F-tab the assembly is captured by the side stile and bottom rail as the screw draws the two sides together. The housing is 11/16 in. wide and 1-3/16 in. tall with a dimple width of 7/8 in. . Used by Northrup and a variety of other sliding patio door manufacturers.

• Used by Northrup and a variety of sliding patio door manufacturers
• When the corner screw passes through the F-tab the assembly is captured by the side stile and bottom rail as the screw draws the two sides together
• 1-1/4 in. diameter concave ball bearing roller
• Stamped steel housing and nylon roller
• Used on metal framed sliding patio doors
• Easy to install
• A Phillips head screwdriver is required for installation
• For further dimensional information, please see the line drawing
